Product Details
05818893 Vibration pump for BOMAG
Part Number:
05818893
Product Name:
Vibration pump
Replacement & Alternative Part Numbers
| Part Number | Relationship | Verification |
|---|---|---|
| 05817050 | Travel pump | Position 1; Qty 1 |
| 07591213 | Pin screw | Position 2; Qty 4 |
| 09280215 | Conical socket | Position 3; Qty 4 |
| 09280113 | Spherical washer | Position 4; Qty 4 |
| 08111218 | Hexagon nut | Position 5; Qty 4 |
| 05540092 | Socket | Position 6; Qty 1 |
| 05542127 | Angular union | Position 7; Qty 1 |
| 05543115 | Union, flanged, SAE | Position 8; Qty 2 |
| 07231217 | Socket-head cap screw | Position 9; Qty 8 |
| 06220330 | Loop ring | Position 10; Qty 2 |
| 05814104 | Half, flange, SAE | Position 11; Qty 4 |
| 05540055 | Socket | Position 12; Qty 1 |
| 05557315 | Distributor | Position 13; Qty 1 |
| 05542123 | Angular union | Position 14; Qty 1 |
| 05544032 | Test connection | Position 15; Qty 1 |
| 05540075 | Socket | Position 16; Qty 1 |
| 05540062 | Socket | Position 17; Qty 1 |
| 05544019 | Test connection | Position 18; Qty 2 |
| 05818893 | Vibration pump | Position 19; Qty 1 |
| 07141242 | Hexagon bolt | Position 20; Qty 2 |
| 08591330 | Washer | Position 21; Qty 2 |
| 05540058 | Socket | Position 22; Qty 2 |
| 05544019 | Test connection | Position 23; Qty 2 |
| 05540054 | Socket | Position 24; Qty 2 |
| 05540073 | Socket | Position 25; Qty 1 |
| 05540045 | Socket | Position 26; Qty 1 |
| 05540075 | Socket | Position 27; Qty 1 |
| 58090118 | Mounting flange | Position 28; Qty 1 |
| 07141035 | Hexagon bolt | Position 29; Qty 6 |
| 08511021 | Washer | Position 30; Qty 6 |
| 07141027 | Hexagon bolt | Position 31; Qty 6 |
| 08511021 | Washer | Position 32; Qty 6 |
| 07231023 | Socket-head cap screw | Position 34; Qty 8 |
| 09221400 | Circlip,internal | Position 35; Qty 1 |
| 58090116 | Lever | Position 36; Qty 1 |
| 07140641 | Hexagon bolt | Position 37; Qty 2 |
| 08510612 | Washer | Position 38; Qty 4 |
| 08130611 | Safety nut | Position 39; Qty 2 |
| 05542127 | Angular union | Position 40; Qty 1 |
| 06220946 | Loop ring | Position 41; Qty 1 |
| 05615078 | Clamping hub | Position 42; Qty 1 |
| 05615209 | Coupling element | Position 43; Qty 1 |
Applications (1 verified models)
| Brand | Equipment | Model | Serial Prefix / Fitment Note |
|---|---|---|---|
| BOMAG | Construction machinery | BW 213 D-40 | Verified in official BOMAG catalogue; confirm machine serial number and nameplate |
