Product Details
05932134 Handle recess for BOMAG
Part Number:
05932134
Product Name:
Handle recess
Replacement & Alternative Part Numbers
| Part Number | Relationship | Verification |
|---|---|---|
| 58291060 | Door | Position 1; Qty 1 |
| 05939163 | Hinge | Position 2; Qty 2 |
| 07210896 | Lens head screw | Position 3; Qty 4 |
| 07320812 | Countersunk screw | Position 4; Qty 4 |
| 05932134 | Handle recess | Position 5; Qty 1 |
| 07140618 | Hexagon bolt | Position 6; Qty 4 |
| 08751064 | Spring washer | Position 7; Qty 4 |
| 05932135 | Rod | Position 8; Qty 1 |
| 05932136 | Door lock | Position 9; Qty 1 |
| 07320825 | Countersunk screw | Position 10; Qty 2 |
| 05932133 | Pillow block | Position 11; Qty 1 |
| 05932137 | Pillow block | Position 12; Qty 1 |
| 07320657 | Countersunk screw | Position 13; Qty 1 |
| 05932106 | Door catch | Position 14; Qty 1 |
| 05932105 | Base | Position 15; Qty 1 |
| 07210629 | Lens head screw | Position 16; Qty 3 |
| 05990050 | Nut,blind | Position 17; Qty 3 |
| 05581168 | Gas spring | Position 18; Qty 1 |
| 08752084 | Spring washer | Position 19; Qty 2 |
| 87500164 | Claw | Position 20; Qty 1 |
| 07320612 | Countersunk screw | Position 21; Qty 2 |
| 58291099 | Retaining band | Position 23; Qty 1 |
| 07130842 | Hexagon bolt | Position 24; Qty 2 |
| 08510817 | Washer | Position 25; Qty 4 |
| 08130813 | Safety nut | Position 26; Qty 2 |
| 00652145 | dm | Position 27; Qty 100 |
| 08510612 | Washer | Position 28; Qty 2 |
| 08130611 | Safety nut | Position 29; Qty 2 |
| 06510174 | Protection cap | Position 30; Qty 2 |
| 05990051 | Nut,blind | Position 31; Qty 2 |
Applications (1 verified models)
| Brand | Equipment | Model | Serial Prefix / Fitment Note |
|---|---|---|---|
| BOMAG | Construction machinery | BW 216 D-4 | Verified in official BOMAG catalogue; confirm machine serial number and nameplate |
