Product Details
58130143 Drive disc for BOMAG
Part Number:
58130143
Product Name:
Drive disc
Replacement & Alternative Part Numbers
| Part Number | Relationship | Verification |
|---|---|---|
| 05817001 | Transmission | Position 1; Qty 1 |
| 05542124 | Angular union | Position 2; Qty 1 |
| 05548011 | Socket | Position 3; Qty 1 |
| 05817096 | Travel motor | Position 4; Qty 1 |
| 07142042 | Hexagon bolt | Position 5; Qty 2 |
| 08512136 | Round anchor plate | Position 6; Qty 2 |
| 05540062 | Socket | Position 7; Qty 1 |
| 05542126 | Angular union | Position 8; Qty 1 |
| 05814104 | Half, flange, SAE | Position 9; Qty 4 |
| 07231217 | Socket-head cap screw | Position 10; Qty 8 |
| 05543115 | Union, flanged, SAE | Position 11; Qty 2 |
| 06220330 | Loop ring | Position 12; Qty 2 |
| 58130101 | Transmission support | Position 17; Qty 2 |
| 07152030 | Hexagon bolt | Position 18; Qty 16 |
| 08512136 | Round anchor plate | Position 19; Qty 16 |
| 07152020 | Hexagon bolt | Position 20; Qty 16 |
| 08752210 | Spring washer | Position 21; Qty 16 |
| 06129902 | Rubber buffer | Position 22; Qty 16 |
| 07141233 | Hexagon bolt | Position 23; Qty 32 |
| 08511324 | Round anchor plate | Position 24; Qty 32 |
| 08112026 | Hexagon nut | Position 25; Qty 16 |
| 08752210 | Spring washer | Position 26; Qty 16 |
| 58130143 | Drive disc | Position 27; Qty 1 |
| 07132053 | Hexagon bolt | Position 28; Qty 14 |
| 08752210 | Spring washer | Position 29; Qty 14 |
| 08402011 | Hexagon nut | Position 30; Qty 14 |
| 58130185 | Guard | Position 31; Qty 1 |
| 58130120 | Sleeve | Position 32; Qty 2 |
| 07131032 | Hexagon bolt | Position 33; Qty 2 |
| 08752106 | Spring washer | Position 34; Qty 2 |
Applications (1 verified models)
| Brand | Equipment | Model | Serial Prefix / Fitment Note |
|---|---|---|---|
| BOMAG | Construction machinery | BW 216 D-4 | Verified in official BOMAG catalogue; confirm machine serial number and nameplate |
